System
RF Type
RF Frequency
Scan Type
FMCW
X-Band
AESA
Detection Capability
Range at Boresight (@ Group1 Drone / DJI MATRICE350)
Minimum Radial Velocity
Maximum Radial Velocity
(Boosting Mode)
Track Update Time
Number of Simultaneous Detection and Tracking
15km
1m/s
70m/s
(140m/s)
< 1s
2,000+ / 1,000+
Detection Accuracy (RMSE)
Range Accuracy
Radial Velocity Accuracy
Azimuth Angle Accuracy
Elevation Angle Accuracy
< 10m
< 0.1 m/s
< 0.2~0.3
< 0.2~0.3
Specifications
Size (WxHxD)
Weight
Operation Temperature
IP Rating
MIL-STD-461G
MIL-STD-810G
585 × 520 × 280 mm³
65kg (Heatsink 20kg)
-32°C ~ +50°C
IP 66
O
O
Advanced Functions
Al Filtering (Bird, Etc) and Tracking
Al Classification (Type: Flying object, Shipment, Car, Cloud)
Clutter Cancelation
Spotlight Mode
Hovering Detection Mode
Boosting Mode
O
O
O
O
O
O
*Maximum detection range is the Max at Boresight
